| Specification | Descriptions |
|---|---|
| ● Visual Indicator | Red = Power,Green = Good Read |
| ● Optical System: | 640 × 480 pixel resolution |
| ● Light Source: | White Light 6500K and RED LED (650nm) |
| ● Resolution: | 0.1mm (4 mil) |
| ● PCS Value: | 20% or more |
| ● Host Systems Interface: | RS232 and USB interface |
| ● Decodable Capability: |
EAN/UPC,Code 128,Code 39,Code 93,Codabar,Interleaved 2 of 5,Industrial 2 of 5, Matrix 2 of 5,Code 11,MSI,GS1 Databar |
| ● Decodable: | QR, Data Matrix, PDF417 |
| Electrical | |
| ● Voltage: | 5V DC ±5% |
| ● Operation Current: | 200mA |
| ● Stand-by Current: | 50mA |
| Environment | |
| ● Operating Temperature: | (-10℃ to 50℃) |
| ● Storage Temperature: | (-30℃ to 60℃) |
| ● Humidity: | 5% to 95% RH |
| ● Ambient Light Rejection: | 100,000 Lux max(Sunlight) |
| Physical | |
| ● Case Material: | ABS + PC |
| ● Dimension: | L:49mm W:43.5mm H:25.5mm |
| ● Weight: | 70g |
| Decode Ranges and Resolution | |
| Symbol & Density | Range |
| Code 39 (5 mil) | 35mm-70mm |
| UPC/EAN (13 mil) | 40mm-220mm |
| QR code (15mil) | 30mm-200mm |
