| Specification | Descriptions |
|---|---|
| ● Image(Pixels) | CMOS 640 x 480 |
| ● Light Source: | illumination: 6500K White LED Ambient lighting: 0-100,000 Lux |
| ● Resolutions | ≥5mil |
| ● Roll / Pitch / Yaw | 360°, ±30°, ±40° |
| ● PCS value | ≥20% |
| ● Field of view angle | Level 62°, vertical 48.5° |
| ● Host Systems Interface: | RS232 and USB |
| ● Decodable Capability: All 1D Symbology Default OFF |
Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar,Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93, UCC/EAN-128, GS1 Databar, Matrix 2 of 5, Code11, Industrial 2 of 5, Standard 2 of 5,MSI |
| ● Decodable:2D | QR code,Data Matrix, PDF417 |
| Electrical | |
| ● Voltage: | 5V DC ±5% |
| ● Operation Current: | 220mA |
| ● Stand-by Current: | 10mA |
| Environment | |
| ● Operating Temperature: | (-20℃ to 55℃) |
| ● Storage Temperature: | (-30℃ to 70℃) |
| ● Humidity: | 5% to 95% RH |
| Physical | |
| ● Case Material: | ABS |
| ● Dimension: | 62(W)×65.2(D)×22.5(H)mm |
| ● Weight: | 42g |
| ● Cable: | 150cm |
| Decode Ranges and Resolution | |
| Symbol & Density | Range |
| Code 39 (5 mil) | 25mm-70mm |
| UPC/EAN (13 mil) | 30mm-160mm |
| QR code (15mil) | 30mm-160mm |
