| Specification | Descriptions |
|---|---|
| ● Scan Speed: | 1500 scan lines per second |
| ● Scan Lines: | 20 Scan lines in 5 directions |
| ● Light Source: | Visible Laser Diode 650nm |
| ● Resolution: | 5 mil |
| ● PCS Value: | 25% @ UPC/EAN 100% |
| ● Scan Angel | Angle of dip 45° elevation 45° |
| ● Light Source: | 650nm High intensity laser diode |
| ● Scan Pattern: | all-orientation space scanning (20 laser lines, 5directions), Single line scan ; sleep and wake |
| ● Scan Distance (PCS 90% code 39) | 0-200mm for 0.33mm UPC/EAN 100% |
| ● Host Systems Interface: | RS232 and USB (HID) interface |
| ● Decodable Capability: | UPC-A、UPC-E、EAN-13、EAN-8、CODE39、Interleaved 2 of 5 、industrial 2 of 5、Matrix 2 of 5、CODEBAR、CDOE128、CODE93、CODE11、MSI、China Post Code |
| Electrical | |
| ● Voltage: | 5V DC ±10% |
| ● Operation Current: | 265 mA |
| ● Stand by Current: | 200mA |
| Environment | |
| ● Operating Temperature: | 0°C to 50°C |
| ● Storage Temperature: | -20°C to 60°C |
| ● Humidity: | 5% to 95% relative humidity, non-condensing |
| ● Ambient Light Rejection: | 0~4,000Lux（fluorescence），0~100,000Lux（sunlight） |
| Physical | |
| ● Case Material: | ABS + Rubber |
| ● Dimension: | （D*W*H）89mm*108mm*143mm(See Figure 2) |
| ● Weight: | 284g |
| ● Cable: | 1.8m coiled or straight Cable |
