| Specification | Descriptions |
|---|---|
| Wireless Communication | RF 2.4G Wireless |
| Communication Distance | Open space is over 100 meters |
| Memory | 2M memory |
| Main Battery | 2000 mAh, Li-ion Battery |
| Keys | Scannner: One Key Cradle: Two Keys (Channel and Pairing key) |
| LED Indicator | 2 colors LED, Good Read: Blue Light, Recharge Power: RED Light |
| Scan Indicator | Buzzer and LED single |
| Battery Charge Time | Approx. 5 hours per full charge |
| Scan per full charge | 20,000 scans (EAN13) |
| Image (Pixels) | CMOS 640 x 480 |
| Light Source | Aiming: 617nm LED, Illumination 6500K LED |
| Ambient Light Immunity: | Immune to indoor lighting up to 1600 Lux. Immune to sunlight up to 100,000 Lux. |
| Reading Resolution | 1D Code 39 (3mil), 2D QR Code 6.6mil |
| Print contrast Signal | 20% minimum reflective difference |
| Field of View: | 51° (H) x 40° (V) |
| Roll/Pitch/Yaw | 360° / ± 65° / ± 60° |
| Motion Tolerance | Up to 25in. (63.5cm) per second |
| Indicator | Blue LED & beeper |
| Interface | USB and RS232 |
| Symbologies: 2D | PDF417, Data Matrix, QR Code, Aztec, Maxi Code, Han Xin Code |
| Symbologies: 1D | EAN/UPC, Code 128, GS1-128, Code 39, Code 39 Full ASCII, Trioptic Code 39, Code 32, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Standard 2 of 5, Codabar, MSI, Chinese 2 of 5, GS1 DataBar variants, Korean 3 of 5, ISSN/ISBN |
| Electrical | |
| Input Voltage | 5V DC ±5% |
| Power Consumption | 1.65W |
| Current - Standby | 90mA |
| Current - Operating | 200mA |
| Environment | |
| Operating Temperature: | 32° to 122° F / 0° to 50° C |
| Storage Temperature: | -40° to 158° F / -40° to 70° C |
| Humidity: | 5% to 95%, non-condensing |
| Drop/Shock Specifications: | Withstands 10Gs 0.06" double amp |
| Physical | |
| Case Material: | ABS + Rubber |
| Dimension: | Hand Held: L: 166mm W: 66mm H: 96mm Stand: L: 198mm W: 66mm H: 66mm |
| 120g (without cable and package) | |
| Decode Ranges and Resolution | |
| Symbol & Density | Range |
| Code 39 (3 mil) | 30mm-50mm |
| Code 39 (5 mil) | 40mm-150mm |
| UPC/EAN (13 mil) | 50mm-320mm |
| QR Code (15mil) | 30mm-320mm |
