| Specifications | Descriptions |
|---|---|
| Image (Pixels) | CMOS 640 x 480 |
| Light Source | Aiming: 617nm LED, Illumination 6500K LED |
| Ambient Light Immunity: | Immune to indoor lighting up to 1600 Lux. Immune to sunlight up to 100,000 Lux. |
| Reading Resolution | 1D Code 39 (5mil), 2D QR Code 7.5mil |
| Print contrast Signal | 30% minimum reflective difference |
| Field of View: | 34° (H) x 26° (V) |
| Roll/Pitch/Yaw | 360° / ± 55° / ± 55° |
| Indicator | Blue LED & beeper |
| Interface | USB and RS232 |
| Symbologies: 2D | Data Matrix, QR Code, PDF417 |
| Symbologies: 1D | UPC/EAN, Code 128, Code 39, Code 39 Full ASCII, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI, Chinese 2 of 5, |
| Electrical | |
| Input Voltage | 5V DC ±5% |
| Current - Standby | 90mA |
| Current - Operating | 200mA |
| Environment | |
| Operating Temperature: | (-20° to 50° C) |
| Storage Temperature: | (-40° to 80° C) |
| Humidity: | 5% to 95%, non-condensing |
| Physical | |
| Case Material: | ABS + Rubber |
| Demension: | 35.80 x 48 (mm) |
| Decode Ranges and Resolution | |
| Symbol & Density | Range |
| Code 39 (5 mil) | 40mm-90mm |
| EAN (13 mil) | 50mm-300mm |
| QR Code (15mil) | 30mm-220mm |
